Distribution Transformer

The final link in the power grid. High-efficiency oil-filled transformers designed to step down voltage for commercial, residential, and industrial utility use.

BEE Star Rated Pole/Plinth Mount
Rating Range 16 kVA to 2500 kVA
Request Quote

What It Does

While Power Transformers handle transmission, **Distribution Transformers** handle the delivery. They take high voltage from the grid (usually 11kV or 33kV) and step it down to the standard 415V/230V required for factories, buildings, and homes.

Our transformers are designed for 24/7 continuous operation, even at low loads, ensuring minimal "No-Load Losses" to save electricity costs over the unit's lifespan.

Design & Construction

Engineered for durability and low maintenance:

1. Core Construction: We use high-permeability CRGO steel stacked in a mitered joint to reduce magnetic noise and losses.
2. Coil Winding: LV windings utilize paper-insulated copper foil or strip, while HV windings use multi-layer enamel copper wire.
3. Tank & Oil: The hermetically sealed tank is filled with dehydrated mineral oil, preventing moisture ingress and ensuring excellent insulation.
4. Protection: Fitted with an Off-Circuit Tap Changer (OCTC) to manually adjust voltage based on the site's average supply.

Key Features

Low Losses

Compliant with IS 1180 Energy Efficiency Levels (Level 1, 2, & 3).

Compact Design

Optimized tank design for easy installation on poles or concrete plinths.

High Overload Capacity

Designed to withstand temporary spikes in demand without overheating.

Safety Fittings

Includes Explosion Vent, Buchholz Relay (optional), and Oil Level Gauge.

Technical Specifications

Capacity 16 kVA – 2500 kVA
Primary Voltage (HV) 11kV / 22kV / 33kV
Secondary Voltage (LV) 433V / 415V (3 Phase, 4 Wire)
Winding Material Copper / Aluminum (As per customer spec)
Tapping +5% to -5% in steps of 2.5% (Off-Circuit)
Cooling ONAN (Oil Natural Air Natural)
Vector Group Dyn11 (Standard)

Where It's Used

Residential Societies Hotels & Hospitals Shopping Malls Small Manufacturing Units Agriculture Pumps Schools & Colleges
